100x89x3mm SN LH lift off hinge grade 13

The Jedo Lift off Hinge Grade 13 is a high-strength hinge ideal for fire doors and heavy-duty applications. It allows for easy door removal without unscrewing, perfect for maintenance and repairs.

KEY FEATURES:

• Material: Steel
• Finish: Satin Nickel
• Size: With dimensions of 100x89x3mm,
• Mechnical Cycles: 200,000
• Corrosion Resistance: Grade 4
• UKCA / CE: EN 1935 : 2002
• Grade 13 Classification: Meets the Grade 13 standard, providing assurance of durability and strength in demanding environments which supports doors up to 120kg with 3 hinges
• Fire Resistance: FD30/60
• Fittings Included: Comes complete with 16 x wood screws (thread length: 28mm & thread diameter: 5mm)
• Usage: Ideal for both commercial and residential settings where reliability and safety are essential.

We strongly recommend requesting a sample before committing to any cutting and drilling.

STANDARDS & CERTIFICATIONS



n.b fire tested when fitted with Intumescent hinge pad.

Brand

Frelan Hardware
